SPECIFICATIONS

Brand Name: HACHANLUN

Certification: NONE

Choice: yes

High-concerned chemical: none

Model Number: ACR122U

Origin: Mainland China

Smart home platform: Other

semi_Choice: yes

Due to the version update, the appearance of the product will be slightly changed, please note

softwear：

https://drive.google.com/drive/folders/16I6t3MpN5OUY4bdB9jk0rWNYBFN3-x5c?usp=sharing

Specification:

Dimensions: 98mm (length) X 65mm (width) X 12.8mm (height)

Interface: Full-speed Usb

Working Distance: <= 50mm (depending On Label Type)

Power Supply Voltage: Regulated 5 V Dc

Source Current: 200ma (working); 50ma (standby); 100ma (normal)

Working Temperature: 0-50°c

Working Frequency: 13.56 Mhz

Smart Card Interface Support: For Iso14443 Types A And B, For Mifare, For Felica, 4 Types Of Nfc Tags (iso / Iec18092)

Operating System Support: Win 98, Win Me, Win 2000, Win Xp, Win Vista, Win 7, Win Server 2003, Win

Server 2008, Win Xp X64, Win Vista 64-bit, Win 7x64, Win Server 2003x64, Win Server 2008x64, Win Server

Server 2008 R2 X64, Windows Ce 5.0, Linux, Mac (please Find Suitable Software To Support You)

Usb 2.0 Full Speed Interface

Pc/sc-compliant

Read/write Speed Up To 424 Kbps

Built-in Antenna For Contactless Tag Access, With Card Reading Distance Of Up To 50 Mm (depending On Tag Type)

Supports Iso 14443 Type A And B, Felica, And All 4 Types Of Nfc (iso/iec 18092) Tags

Supports For Mifare Ultralight C (via Pseudo Apdus) And For Mifare Plus Sl1 (4 Byte Uid, Via Pseudo Apdus) And Sl3

Supports All 3 Modes Of Nfc: Reader, Card Emulation And Peer-to-peer Modes

Built-in Anti-collision Feature (at Least 1 Card Is Detected When Multiple Cards Are Presented)

Usb Pnp

Application:

1. Network Access Control

2. Bank&paymen

3. Nfc Mobile Ta

4. Public Transportation Terminal

5. Automatic Fare Collectio

6. Physical Access Contro

7. Customer Loyalt

8. Time And Attendanc

9. Contactless Public Phone

10. Vending Machine

Specifications:

Dimension: 98 Mm (l) X 65 Mm (w) X 12.8 Mm (h)

Interface: Usb Full Speed

Operating Distance: <= 50mm (depends On Tag Type)

Supply Voltage: Regulated 5v Dc

Supply Current: 200ma (operating); 50ma (standby); 100ma (normal)
